Description
The Siemens 200 Amp 20-Space 40-Circuit Outdoor Main Breaker Load Center features tangential knockouts that help eliminate the need for conduit offsets. This main breaker load center has an aluminum buss bar along with neutral and ground bars that feature multiple 1/0 conductor terminals. The side-hinged enclosure of this load center offers an easily removable door.
- Aluminum buss bar
- Neutral and ground bars feature multiple 1/0 conductor terminals
- Side-hinged enclosure has a removable door which can be removed by backing out only a single screw
- Single-phase, 200 Amp, 240-Volt maximum
- Meets UL and ANSI safety requirements
- Tangential knockouts help eliminate the need for conduit offsets
- For use with service or non-service entrance applications
- Use with residential / commerical metering equipment applications
Features
| Item Weight | 32.4 |
| Number of Spaces | 20 |
| Mounting Type | Bolt On |
| Voltage (volts) | 120/240 |
| Load Center Type | Main Breaker |
| Load Center Mounting Type | Surface |
| Electrical Product Type | Load Center |
| Indoor/Outdoor | Outdoor |
| Number of Circuits | 40 |
| Returnable | 180-Day |
| Phase Type | 1 Phase |
| Product Weight (lb.) | 32.4 |
| Maximum Amperage (amps) | 200 |
| Load center height (in.) | 30.5 |
| Load center width (in.) | 15.4 |
| Load center depth (in.) | 5.12 |
| Certifications and Listings | UL Listed |
| Manufacturer Warranty | 1 YEAR |
