Description
BrassCraft ProCoat stainless steel connectors deliver outstanding flexibility with advanced corrosion resistance, both inside and outside. BrassCraft’s patented integrated dielectric sleeve isolates dissimilar metals within the waterway, where galvanic and electrolytic corrosion have their greatest potential. This separation provides complete protection against galvanic corrosion that can deteriorate the connector and cause leaks. In addition, the integrated dielectric sleeve eliminates the need to install an additional dielectric union, reducing time and installation costs. The corrugated stainless steel delivers superior flexibility over copper and braided stainless steel without kinking or flattening for a quick and simple installation. The stainless steel core is protected from corrosion and deterioration with BrassCraft’s exclusive ProCoat clear coat that provides protection from harsh cleaning and plumbing repair chemicals.
- California residentssee Prop 65 WARNINGS
- Coated stainless steel tube 3/4 in. I.D. x 12 in. L
- End connections: (3/4 in. I.D.) 3/4 in. FIP x 3/4 in. FIP
- Use with electric or gas water heaters or softeners. Use only to connect water
- Corrugated stainless steel, delivers superior flexibility without kinking or flattening
- Full flow, maximum performance with a 3/4 in. internal diameter
- Exclusive ProCoat clear coat, provides superior corrosion resistance to deterioration from harsh external chemicals, UV rays and salt
- Integrated dielectric sleeve isolates dissimilar metals within the waterway to help protect the connector from internal corrosion
- Integrated dielectric sleeve eliminates need to install an additional dielectric union
- Pliable nitrile rubber washer requires less torque to seal especially on rough nipple surfaces
- 100% leak tested
- Temperature rating: 40° to 180° F (NSF61 maximum 82° C)
- Pressure rating: 125 psi maximum
- Designed, machined and assembled in the USA
- CSA and IAPMO certified
- No-lead certified
Features
| Item Weight | 0.2931 |
| Material | Coated Stainless Steel |
| Compatible Brand/Model | Fits Most Brands |
| For Use With | Electric Tank,Gas Tank |
| Finish Family | Silver Metallic |
| Pack Size | 1 |
| Returnable | 180-Day |
| Product Weight (lb.) | 0.2931 lb |
| Product Depth (in.) | 12.000 in |
| Product Width (in.) | 0.750 in |
| Product Height (in.) | 0.750 in |
| Manufacturer Warranty | Limited Manufacturer Warranty |
